Excavator Hydraulic Tree Shear
CTHB excavator hydraulic tree shear features a wear-resistant steel body forged from a single piece and an integrated hydraulic protection structure; it is lightweight yet durable and compatible with excavators of various tonnages.
Powered by the excavator’s robust hydraulic system, the tree shear drives its blades to rapidly cut, clear, and transport trees and brush. It operates by drawing hydraulic fluid from the excavator’s auxiliary circuit to actuate the hydraulic cylinder, closing the blades in a scissor-like motion to sever tree trunks.
Its multi-functional design allows for a series of operations such as felling, pruning, grabbing, stacking, and loading trees to be completed on a single device, avoiding the hassle of frequently changing attachments.
It significantly enhances safety and operational efficiency in forestry management, roadside clearing, and land leveling.
Power in every cut, ease in every grab.
Heavy-duty shear, 360° rotation, low maintenance for all excavators
Specification
| Model | Unit | CT200 | CT250 | CT350 | CT380 |
| Carrier Weight | ton | 1.8-5 | 6-9 | 12-17 | 18-28 |
| Max Opening | mm | 535 | 585 | 825 | 1050 |
| Blade Thickness | mm | 18 | 20 | 28 | 28 |
| Cut Diameter (MAX) | mm | 200 | 250 | 350 | 380 |
| Weight | kg | 205 | 365 | 870 | 1130 |
| Rotating Type | Option | 360° Hydraulic Rotation | |||
Maximum cut diameter is achieved in optimal, soft wood scenarios only and may require a few attempts.
Hard wood performance is typically 25% less than the stated maximum soft wood cut diameter.
*This specification may be changed without notice for performance improvement.
*Customization available.
- Wear-resistant body and hardened blades for long service life
- Built-in hydraulic overload protection ensures powerful cutting force and prevents slipping on wood
- Wraparound clamping allows for controlled tree felling, ensuring safety and compliance
- Exceptional operational efficiency and versatile multi-functionality
